TER-43-3800-100W
Load, 4.3-10 male, 100 Watt

Rev : E | Rev date : 21 Feb 2023

The 43-TER Series are coaxial loads which operate from DC up to 3.8 GHz.The products are ideally suited for termination of unused ports in distributed antenna systems or in RADIAFLEX® radiating cables systems.

FEATURES / BENEFITS

  • Ideal for all kind of DAS applications
  • Finned termination for optimized heat disspation
  • Low VSWR

Technical features

General Specifications

Product TypeLoad
Techn. ApplicationIndoor

Electrical Specifications

Frequency Range MHzDC-3.800
Impedance Ohm50
Max. VSWR / Return Loss, dBVSWR/dB/19
Total Input Power W100

Mechanical Specifications

Input Connector Type4.3-10 male

Temperature Specifications

Temperature Range °C (°F)-25 to 65 (-13 to 149)
Environmental ClassIndoor

External Document Links

Notes
